Tjernlund Fireplace Chimney Fan Model RT750H

This rooftop chimney fan is great if your fireplace starts hard or if it has a back draft.  This chimney fan is also ideal for chimneys that are too short.  Allows you to enjoy a fire without any smoky backup even if you have moist or hard to ignite fuel.  Once you have your fire burning you can adjust the variable speed control knob in order to get maximum efficiency.  It connects easily with metal or tile lined flues.

The patented auxiliary cooling system protects the motor from excessive heat even when the chimney fan is turned off.  This chimney fan has a self cleaning, backward inclined impeller which will repel soot build-up. The clamshell design means that it can be installed easily and allows you maximum accessibility to the chimney or vent pipe during inspection or service. We recommend a professional contractor for choosing and installation of the proper product.

Specifications: Voltage: 120 VAC RPM: 1550 Amps: 1.2 Power: 1/12 hp, .063 kW Weight: 34 pounds ETL Listed to UL378, UL705, & CAN/CSA B255-M81 Dimensions (in inches): A: 17 1/2 B: 16 3/4 C: 8 D: 16 E (inlet): 7 15/16 F: 14 1/2
Download the Chimney Fan Installation Instructions  - Note - these instructions are intended as an aid to qualified, licensed personnel.   Download the Chimney Fan Submittal Sheet
