Home > Industrial Fans > 20 Inch EZ-Breeze Variable Speed HAF Basket Fan

20 Inch J&D Mfg. EZ-Breeze HAF Basket Fan

J&D Manufacturing
Industrial Fans
20 Inch EZ-Breeze Variable Speed HAF Basket Fan

20 Inch EZ-Breeze Variable Speed HAF Basket Fan

Use this basket fan for even circulation throughout your space and to create uniform temperatures throughout your building.  This HAF (horizontal air flow) fan is a high efficiency basket fan that efficiently cools. It is available in two different motor configurations, either 1/10 horsepower or 1/3 horsepower.

Features a direct, drive, high efficiency motor that is totally enclosed and maintenance free.    The powder coated fan guards meets OSHA 1910.212(a)(5) requirements.

This basket fan can be installed right out of the box because it comes fully assembled. It includes a mounting bracket with the nuts and bolts needed to mount it. It is wired with an attached 10 foot cord with a 3-prong plug which is pre-wired for 115 Volts.

Features:

  • Corrosion resistant white powder coated fan guards
  • 3 aluminum blades
  • 10 foot cord
  • Efficient variable speed motor
  • Aluminum propellers designed to reduce ambient noise levels
  • Direct drive high efficiency motor
  • Two year warranty
  • UL/CUL recognized
  • Choice of 1/10 HP or 1/3 HP
  • Download the User Manual

Specifications:

Model HP Volts Amps Hz Spd^ FPM* Thrust
 (lbf)
Thrust Eff. Ratio ** kW Tested
RPM
Thrust CFM Thrust CFM/
 Watt
VDB20G 1/10 115~ 1.0 60 1/Var 575 0.80 7.9 .102 1,715 1680 16.5
VDB203G 1/3 115 3.5 60 1/Var 870 3.19 8.7 .367 1685 3340 9.1


Notes:

  • ~ This unit comes pre-wired for 115 Volts (may be rewired by an electrician for 230 Volts)
  • ^Variable speed fans require separate variable speed control to adjust fan speed
  • *FPM (Feet per Minute) - The velocity measured center line at a distance 5 times the prop diameter
  • ** Thrust efficiency ratio is calculated by dividing the Thrust (lbf) by the kW

Warning. This product can expose you to chemicals including lead or chromium which are known to the State of California to cause cancer and or birth defects or other reproductive harm. For more information to go www.P65Warnings.ca.gov


20-inch-variable-speed-haf-basket-fan.html
$139.00
20 Inch EZ-Breeze Variable Speed HAF Basket Fan
20 Inch EZ-Breeze Variable Speed HAF Basket Fan20 Inch EZ-Breeze Variable Speed HAF Basket Fan20 Inch EZ-Breeze Variable Speed HAF Basket Fan
Item #JD VDB20G
AvailabilityUsually ships the next business day
Sale Price$139.00
Options
Quantity


Description

20 Inch EZ-Breeze Variable Speed HAF Basket Fan

Use this basket fan for even circulation throughout your space and to create uniform temperatures throughout your building.  This HAF (horizontal air flow) fan is a high efficiency basket fan that efficiently cools. It is available in two different motor configurations, either 1/10 horsepower or 1/3 horsepower.

Features a direct, drive, high efficiency motor that is totally enclosed and maintenance free.    The powder coated fan guards meets OSHA 1910.212(a)(5) requirements.

This basket fan can be installed right out of the box because it comes fully assembled. It includes a mounting bracket with the nuts and bolts needed to mount it. It is wired with an attached 10 foot cord with a 3-prong plug which is pre-wired for 115 Volts.

Features:

  • Corrosion resistant white powder coated fan guards
  • 3 aluminum blades
  • 10 foot cord
  • Efficient variable speed motor
  • Aluminum propellers designed to reduce ambient noise levels
  • Direct drive high efficiency motor
  • Two year warranty
  • UL/CUL recognized
  • Choice of 1/10 HP or 1/3 HP
  • Download the User Manual

Specifications:

Model HP Volts Amps Hz Spd^ FPM* Thrust
 (lbf)
Thrust Eff. Ratio ** kW Tested
RPM
Thrust CFM Thrust CFM/
 Watt
VDB20G 1/10 115~ 1.0 60 1/Var 575 0.80 7.9 .102 1,715 1680 16.5
VDB203G 1/3 115 3.5 60 1/Var 870 3.19 8.7 .367 1685 3340 9.1


Notes:

  • ~ This unit comes pre-wired for 115 Volts (may be rewired by an electrician for 230 Volts)
  • ^Variable speed fans require separate variable speed control to adjust fan speed
  • *FPM (Feet per Minute) - The velocity measured center line at a distance 5 times the prop diameter
  • ** Thrust efficiency ratio is calculated by dividing the Thrust (lbf) by the kW


Warning. This product can expose you to chemicals including lead or chromium which are known to the State of California to cause cancer and or birth defects or other reproductive harm. For more information to go www.P65Warnings.ca.gov


Question: How does this fan turn on and off?
Answer: The 20 Inch Basket Fan can be wired to a variable speed controller or you would just plug it in to turn in on and unplug it to turn off.
Question: Does this fan oscillate?
Answer: No.
